1. Input voltage: 6.5-36V (the input voltage is lower than 6.5V, the current accuracy is inaccurate, and the LCD display is abnormal if it is lower than 5.5V)
2. Output voltage: 1.2-32V, the default output is 5V step-down type, the output voltage can only be lower than the input voltage, and the voltage difference is more than 2V
3. Output current: It can work stably at 3.5A for a long time, and it can reach about 4.5A with fan enhanced heat dissipation (adjustable limit current can reach about 4.2-4.5A)
4. Output power: natural heat dissipation 50W (within 3.5A), plus fan to enhance heat dissipation 75W
5. Voltage display: resolution 0.05V, range 1.2-32V
6. Current display: resolution 0.005A, range 0-4.5A
7. Conversion efficiency: about 94%, depending on the voltage difference and current efficiency
8. Working current: about 30mA
9. Input reverse polarity protection: yes
10. Anti-backflow at the output: no (if charging the battery, first power on the module and then connect the battery, and ensure that the battery voltage is lower than the output voltage; if possible, connect an anti-backflow diode in series with the output positive pole)
11. Short circuit protection: yes
12. Size: about 70.5x48.4x28mm
13. Weight: about 65g
